Introduction
FF shaft formwork is a formwork system specially designed for the internal formwork support of elevator shafts, flue shafts, ventilation shafts, light shafts and other closed shafts, which realizes the arrangement and disassembly of the internal formwork of the shaft. The shaft formwork system includes steel columns, steel (aluminum) formwork, adjustable construction platform, column height adjustment parts, and pedal cover.
Features:
FF shaft formwork system realizes the arrangement and disassembly of the internal shaft formwork, getting rid of the traditional shaft construction wooden formwork or aluminum formwork splicing construction techniques that are troublesome “one layer per frame, one layer per demoulding, tedious disassembly”
Product advantages:
1. Convenient construction and overall disassembly and assembly:
The column structure is simple. By rotating the screw at the top and driving the middle axis to move upward, the shaft template can be retracted and reset;
2. Lower cost:
The template adopts a steel template system, which is lower in cost;
3. Stable and non-deformed
The template is welded with super-strong steel, which has high strength and small deformation compared to aluminum formwork;
4. Excellent construction effect
The manual operation efficiency of traditional shaft templates is low, the assembly size accuracy is poor, and leakage is prone to occur during on-site pouring, resulting in poor concrete surface forming effect and worrying project quality. Using the FF shaft template system, the construction efficiency is high and the surface forming effect of the shaft concrete is excellent.
5. Wide range of applications
The new elevator shaft base adopts an oblique support construction platform, which does not need to pre-embed the claw arm box in advance, and has a wider range of applications; the four corners have built-in height adjustment devices, which have a larger adjustment range and are easier to adjust; the upper cover adopts a modular design, which can be adjusted in both length and width directions, and has a wider range of applications.
6. Safety
The operating platform temporarily constructed by traditional shaft molds has a low safety factor and poses a great safety hazard. It is easy to cause scaffolding collapse accidents, resulting in huge casualties. Using the FF elevator shaft mold system, the construction safety factor is greatly improved.
